Ui12

12-channel Digital Mixer With Wireless Control

Ui12

The Ui Series mixers feature cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices, and can use up to 10 control devices simultaneously. In addition, the Ui12 and Ui16 each feature built-in HARMAN signal processing from dbx, DigiTech and Lexicon, including dbx AFS2, DigiTech Amp Modeling, and more. Both models feature fully recallable and remote-controlled mic gain and phantom power, along with 4-band parametric EQ, high-pass filter, compressor, de-esser and noise gate on input channels.

Both mixers offer 31-band graphic EQ, noise gate and compressor on all outputs, plus real-time frequency analyser (RTA) on inputs and outputs. Built in are three dedicated Lexicon FX busses: Reverb, Delay and Chorus. In addition, mixer controls include Subgroups, Mute groups and View groups, among others. The Ui Series mixers feature full Show/Snapshot recallability with channel recall safes. while security lockout features allow customization of device access to only specific functions and mixes if needed. Both mixers also offer independent network interfaces on board for simultaneous control by Wi-Fi and Ethernet, plus a floor-ready rugged chassis for live applications.

The Ui12 also features four XLR combo mic/line inputs, four XLR mic inputs, two channels of Hi- Z/instrument inputs, as well as a stereo RCA line input. A 2-channel USB media player is included, along with two balanced XLR Aux outputs, two quarter-inch headphone outputs with level control, plus balanced stereo XLR and quarter-inch main outputs. Two-channel USB audio playback is compatible with MP3, WAV and AIFF formats.

Software Demo

Choose a screen size to preview the Ui12 web-based mixer application:

Phone
Phone
Tablet
Tablet

Features

  • Tablet/PC/Smartphone Controlled Digital Mixer
  • Integrated Wi-Fi
  • Cross-platform compatibility with iOS, Android, Windows, Mac OS, and Linux devices
  • Use up to 10 control devices (tablets, phones, PCs) simultaneously
  • Legendary Harman Signal Processing from dbx®, Digitech®, and Lexicon®
  • Fully recallable and remote-controlled mic preamps
  • 4-band Parametric EQ, High-Pass Filter, Compressor, De-esser and Noise Gate on input channels
  • 31-band Graphic EQ, Noise Gate and Compressor on all outputs
  • Real-Time Frequency Analyser (RTA) on inputs and outputs
  • 3 dedicated Lexicon® FX effects processors: Reverb, Delay and Chorus
  • Subgroups, Mute Groups, View Groups, and more mixer controls
  • Show/Snapshot recall with channel safes and security lockout
  • Password-protected Access limitation system
  • Sync ID (multiple browser windows staying in channel Sync)

Videos

















































































Downloads

  Version Language Size Uploaded
Firmware
platform icon Ui12 Firmware Update
version 1.0.7548, updated: Jan 2018
1.0.7548     52.8 MB Jan 2018
Ui12 Firmware Update Release Notes     29.3 KB Jan 2018
platform icon Ui12 Firmware Update v1.0.7048 [PREVIOUS VERSION]
updated: Jan 2018
    52.6 MB Jan 2018
Ui12 Firmware Updater Read Me File     4.31 KB Jan 2018
  Version Language Size Uploaded
Owners Manuals
file type icon Ui12/16 User Guide v3.0 (English)
en updated: Mar 2024
  en  37.1 MB Mar 2024
file type icon Ui12/16 User Guide V3.0 (Chinese Version)
zh updated: Mar 2024
  zh  14.2 MB Mar 2024
file type icon Ui12/16 User Guide V2.8 (French Version)
fr updated: Mar 2024
  fr  6.76 MB Mar 2024
file type icon Ui12/16 User Guide V2.8 (German Version)
de updated: Mar 2024
  de  6.82 MB Mar 2024
file type icon Ui12/16 User Guide V2.8 (Portuguese Version)
updated: Mar 2024
    6.76 MB Mar 2024
file type icon Ui12/16 User Guide V2.8 (Russian Version)
updated: Mar 2024
    24.2 MB Mar 2024
file type icon Ui12/16 User Guide V2.8 (Spanish Version)
es updated: Mar 2024
  es  6.78 MB Mar 2024
Brochures
file type icon Ui12/16- Brochure
en updated: May 2023
  en  28.6 MB May 2023

Specifications

Height 85mm (3.3")
Width 177mm (7.0")
Length 320mm (12.6")
Weight 2.29kg (5.0lb)
