Mini Stagebox 32R/16R

Low-cost option for stage connectivity

Mini Stagebox 32R/16R
Larger Images

The new Mini Stagebox range from Harman's Soundcraft provides a simple solution to stage connectivity offering a lower-cost option for many systems where the modularity and configurability of the larger systems are not required.

The Mini Stagebox 32R (3U) provides 32 analogue inputs and 8 analogue line outputs, with 4 pairs of AES outputs, providing a total I/O capacity of 32 inputs and 16 outputs, with the Mini Stagebox 16R (2U) model providing 16 analogue inputs and 8 line outputs making a 16 x 8 matrix. They connect to any of the Soundcraft Si Expression, Si Compact, Si Performer, Si Series and Vi Series consoles via a MADI card fitted to the option card slot.

The Mini Stagebox models contain an integral PSU so are completely self-contained and sit comfortably stage-side.

The new units are part of the ViSi Connect range of interface options for all Soundcraft mixing consoles which includes the Compact and Vi Stageboxes and a range of option cards such as MADI, AES, CobraNet and AES.

Both models are supplied with the stagebox card installed, plus the corresponding card for an Si series console (Vi console MADI cards sold separately)

Part Numbers

  All Regions
Mini Stagebox 16R Cat5 MADI 5036292
Mini Stagebox 32R Cat5 MADI 5036290

Compatibility

Vi1   Si Impact   Si1, Si1+
Vi2 Si Performer Si2, Si2+
Vi4 Si Expression Si3, Si3+
Vi6 Si Compact
Vi3000
Vi5000
Vi7000

Downloads

  Version Language Size Uploaded
Owners Manuals
file type icon Mini Stagebox 16 User Guide
en updated: Mar 2024
  en  1.44 MB Mar 2024
file type icon Mini Stagebox 32 User Guide
en updated: Mar 2024
  en  329 KB Mar 2024
